Brand – Diamond C Trailers
Model – LPT-GN208
Length/Width – 14’ x 82”
GVWR – 18,000lbs
Dry Weight – 6,540lbs
Payload – 11,460lbs
Axles – (2) 8K Drop Axles, Oil Bath
Axles – Straight Axles (82” Wide Frame and +4” Ground Clearance)
Brakes – Electric Drum
Suspension – Slipper Roller Springs
Pull Type – 12” Engineered Gooseneck Package
Dump Main Frame – Engineered Beam Frame
Dump Body Frame – 5” x 2” x 3/16” Rectangle Tube
Body Thickness – 7ga (3/16”) Body, Floor, & Sides (Super Duty Body Upgrade)
Sides - 32” Tall Sides (7ga)
Side Extensions – Board Brackets w/ Raised Front (Pacesetter UPGRADE)
Hoist – 3 Stage Telescopic Cylinder
Ramps – HD 78” Rear Slide-In Ramps (3” Channel)
Ramps – Rear Stabilizer Drop Legs (Pacesetter UPGRADE)
Gate – 3-way gate (with Hold Back System)
Paint – DM Difference Maker Powder Coating System
Paint Color – Cement Gray
Cross-Members – 3” I-Beam on 12” Centers (UPGRADE)
Gooseneck Coupler – 2 5/16” Ball, 30K Square Load Leveler (UPGRADE)
Jack – Dual 20K Hydraulic Jacks (Pacesetter UPGRADE)
Storage – Full width Diamond Plate Neck Box
Hydraulic Power – Power-Up, Gravity Down (with High Flow KTI Pump)
Bed Control – Corded Remote, 14’
Battery/Charger – Group 27 Series w/110V 5-amp Charger
Battery/Charger – Solar Charging System, 7 watts (Pacesetter UPGRADE)
Fenders – 3/16” Diamond Plate, Super Heavy Duty (Pacesetter UPGRADE)
Steps – Fork Holder Step – Driver Side (Pacesetter UPGRADE)
Lights – All LED Lights
Stake Pockets – Stake Pockets on each Upright
Tie Downs – (2) Extra – 5/8” D-Rings, Total of (6) (UPGRADE)
Tarp – 20’ Long Arm, Easy Roll Tarp System
Wiring – Sealed Wiring Harness
Tire Size – 215/75 R17.5, 18ply
Wheel Color – Black
Matching Spare Tire and Mount
